| Genset Model | 50HZ, 400/230V | Diesel Engine | Alternator |
Overall Size (mm) |
Weight (kg) |
||||||||
| Prime Power(kW) | Prime Power(kVA) | Model |
Rated Power (kW) |
No. of Cylinder |
Bore xStroke (mm) |
Displacement (L) |
Compression ratio | Rated Fuel Consumption (g/kw.h) | PRM | Model | |||
| CCFJ30Y | 30 | 37.5 | YC4D55Z-C12 | 40 | 4 | 108*115 | 4.214 | 17:1 | 205 | 1500 | MP-H-30-4 | 1770*750*1200 | 760 |
| CCFJ50Y | 50 | 62.5 | YC4D85Z-C22 | 60 | 4 | 108*115 | 4.214 | 17:1 | 205 | 1500 | MP-H-50-4 | 2080*750*1200 | 940 |
| CCFJ64Y | 64 | 80 | YC6108ZC | 80 | 6 | 108*125 | 6.871 | 17.5:1 | 205 | 1500 | MP-H-64-4 | 2080*750*1200 | 940 |
| CCFJ75Y | 75 | 94 | YC6108ZLCA | 90 | 6 | 108*125 | 6.871 | 17.5:1 | 205 | 1500 | MP-H-75-4 | 2100*750*1200 | 1210 |
| CCFJ100Y | 100 | 125 | YC6B165L C22 | 120 | 6 | 108*125 | 6.871 | 17.5:1 | 205 | 1500 | MP-H-100-4 | 2100*750*1200 | 1420 |
| CCFJ120Y | 120 | 150 | YC6A200L C20 | 145 | 6 | 108*132 | 7.252 | 17:1 | 205 | 1500 | MP-H-120-4 | 2100*970*1500 | 1610 |
| CCFJ150Y | 150 | 188 | YC6MK240L C22 | 176 | 6 | 123*145 | 10.338 | 17.5:1 | 205 | 1500 | MP-H-150-4 | 2700*1050*1500 | 2250 |
| CCFJ200Y | 200 | 250 | YC6MK330C | 240 | 6 | 123*145 | 10.338 | 17.5:1 | 205 | 1500 | MP-H-200-4 | 2700*1050*1500 | 2250 |
| CCFJ250Y | 250 | 312.5 | YC6K420L C20 | 294 | 6 | 129*155 | 12.16 | 16.5:1 | 200 | 1500 | MP-H-250-4 | 3260*1100*1600 | 2420 |
| CCFJ300Y | 300 | 375 | YC6K450L C20 | 330 | 6 | 129*155 | 12.16 | 16.5:1 | 200 | 1500 | MP-H-300-4 | 3260*1100*1600 | 2480 |
| CCFJ400Y | 400 | 500 | YC6TD600L C20 | 441 | 6 | 152*180 | 19.59 | 14:1 | 198 | 1500 | MP-H-400-4 | 3480*1160*1900 | 3500 |
| CCFJ600Y | 600 | 750 | YC6CL960L C20 | 706 | 6 | 200*210 | 39.58 | 14.5:1 | 198 | 1000 | MP-H-600-4 | 4180*1320*2100 | 6600 |
| CCFJ1000Y | 1000 | 1250 | YC8CL1630L C20 | 1200 | 8 | 200*290 | 72.88 | 14.5:1 | 198 | 1000 | MP-H-1000-4 | 4770*1380*2100 | 10500 |
Marine generators are used to power the AC electrical system on a vessel
✔ Climate Control: Running air conditioning and heating systems is the most common reason for installing a marine generator on the ship.
✔ Galley Appliances: generator sets powering microwaves, electric stoves/ovens, induction cooktops, refrigerators, freezers, blenders, and coffee makers.
✔ Comfort and Convenience: Yuchai generator supply power for operating water makers , water heaters, washing machines, and dryers.
✔ Entertainment Systems: Running large entertainment systems, flat-screen TVs, gaming consoles, and sound systems throughout the boat.
✔ Battery Charging: While often done via a DC alternator, a generator can power a large battery charger or inverter/charger to rapidly replenish the house bank batteries that run DC systems (lights, pumps, navigation electronics).
✔ Tools and Workshop: On larger vessels and workboats, generators power workshops, dive compressors, cranes, and winches.
✔ Safety Systems: gensets powering critical systems like radars, emergency communications, and floodlights during extended voyages
